Radar technologies

SAR
Radar imaging of the surface
Day and night
Independent of daylight
up to 36 km
Stated radar payload range

Radar technologies

SAR
Radar imaging of the surface
Day and night
Independent of daylight
up to 36 km
Stated radar payload range
LEONARDO SAR
up to 36 km
Imaging a strip of ground
Strip
Detailed imaging of a selected ground area
Spot

Radar complements optical imaging

Radar imagery
Another view of the area of interest
Complementing EO data
Joint assessment of available sensor data

Radar complements optical imaging

Radar imagery
Another view of the area of interest
Complementing EO data
Joint assessment of available sensor data

Radar reconnaissance beyond the optical image

Synthetic aperture radar complements cameras when distance, darkness or low optical contrast limit their usefulness. Combining radar observations with EO and ELINT data builds a more complete situational picture from one unmanned platform.

LEONARDO SAR
up to 36 km

A wide strip or a selected area

Strip SAR
Imaging a strip of ground
Spot SAR
Detailed imaging of a selected ground area

A wide strip or a selected area

Strip SAR
Imaging a strip of ground
Spot SAR
Detailed imaging of a selected ground area

Wide-area coverage or a detailed look

Strip images a continuous ground swath; Spot focuses on a selected area. The appropriate radar is chosen for the required detail and coverage. No single range applies to every target and resolution; GPR is a separate sensor for subsurface surveys.

Imaging a strip of ground
Strip
01 03Equipment
Electronic warfare

Configure your payload

Discuss requirements

What do you need to achieve?

Select the required function instead. We will work with you to specify the equipment.

Continue to enquiry and selection (0)

References and projects

Leonardo · Gabbiano on Skyspotter 150A

LIAZ and Leonardo jointly presented Skyspotter 150A with Gabbiano Ultra-Light radar in 2018. Their cooperation began in 2017.

EDR · 18 Oct 2018
Choose a specific device for integration assessment4 catalogue models · specifications and sources

Models shown: 4 / 4

Leonardo

Gabbiano TS Ultra-Light

Radar · complement to optical monitoring

Presented on 150A · 2018

Radar surveillance as a separate sensor option alongside camera systems.

Weight in the 2023 brochure
24 kg
Launch architecture (2017)
2 units: antenna + RTP
Launch antenna (2017)
12 inches
Scanning
Mechanical
Mapping modes
Strip SAR / Spot SAR
Ground moving target indication
GMTI

The 2017 and 2023 specifications refer to different product revisions. Leonardo must confirm the current configuration and range for the intended mission.

Radarteam Sweden AB

Cobra Plug-In GPR

GPR · subsurface survey

152/W project · 2026

Low-frequency GPR for geological and engineering surveys. It images subsurface interfaces, not a landscape image like SAR.

Configuration
Single channel, unshielded antenna
Antenna alternatives
SE-40 / SE-70 / SE-150
Centre frequency at εr = 9
52 / 80 / 124 MHz
SE-40 / 70 / 150 lengths
200 / 139 / 92 cm
Variant weights listed by SPH
5.2 / 4.9 / 4.6 kg
Data output
SEG-Y (.sgy), geotagged traces

Specifications refer to SPH Engineering's airborne variant. Antenna, installed weight and achievable depth require confirmation for the 152/W project; follow-up surveys must establish water presence and quality.

Leonardo

PicoSAR

AESA radar · ground mapping

Catalogue alternative · integration unconfirmed

A compact electronically scanned radar for synthetic-aperture mapping.

Weight
10 kg
Power consumption
< 300 W
Supply voltage
28 V DC
Radar band
X
Electronic scan range
±45°
Mapping mode
Strip SAR

Reference MM07774 (2019); the manufacturer must confirm the current variant. Mapping resolution and range are interdependent. Installation also involves the antenna, processing and accessories.

IMSAR

NSP-3

Compact SAR radar

Catalogue alternative · integration unconfirmed

A lightweight radar system combining an electronics module with a separate antenna.

Weight
5.9 lb / 2.7 kg, manufacturer figure
Power consumption
< 74 W
Supply voltage
28 V DC
Radar band
Ku
SAR resolution range
0.1–10 m
SAR range at 1 m resolution
3–13 km

Finest resolution and greatest range cannot automatically be combined. IMSAR must confirm the configuration for the required mode.
